PRODUCTS
Autorefractometer AR-910
- 3D autofucus technology for automatic eye tracking and measurement
- High precision measurement with newly designed optical structure
- Easy operation with intelligent touch screen
- One-touch auto tracking and measurement in 10 seconds
- Retro-illumination image for better eye observation
- Independent fogging and measurement system for improved accuracy
Description
The LENSit Auto-Refractometer AR-910 is a fully automatic auto refractometer designed for quick and easy measurement of a patient’s refraction. Featuring 3D auto-tracking and focus, the AR-910 can automatically find and measure the patient’s eyes, eliminating the need for manual alignment. The instrument also uses LD light and a high-sensitivity CCD camera to capture clear and sharp images, even for patients with cataracts.
In addition to its automatic features, the AR-910 is also easy to use. The instrument features a tiltable LCD touchscreen and a motorized chin rest for easy patient positioning. The built-in thermal printer allows for quick and convenient printouts of refraction results.
Specifications
| SPECIFICATIONS | KR-9 | AR-9 | ||
|---|---|---|---|---|
| REFRACTIVE MEASUREMENT RANGE | Sphere (S) | Measurement Range | -25D~+25D (VD=12) | -25D~+25D (VD=12) |
| Unit | 0.12D, 0.25D | 0.12D, 0.25D | ||
| Cylinder (C) | Measurement Range | 0D~±10D (VD=0) | 0D~±10D (VD=0) | |
| Unit | 0.12D, 0.25D | 0.12D, 0.25D | ||
| Symbol | -, +, ± | -, +, ± | ||
| Axis (A) | Measurement Range | 0°~180° | 1°0°~180° | |
| Unit | 1° | 1° | ||
| Vertex Distance | 0, 10, 12, 13.5, 15mm | 0, 10, 12, 13.5, 15mm | ||
| Minimum Pupil Diameter Measurable | ϕ2.0,mm | ϕ2.0mm | ||
| CORNEAL CURVATURE RADIUS MEASUREMENT | Corneal Curvature Radius | Measurement Range | 5.0mm - 10.mm | - |
| Unit | 0.01mm | - | ||
| Corneal Refractivity | Measurement Range | 33.00D~67.00D (where corneal refractive index n=1.3375) | - | |
| Unit | 0.12D, 0.25D | - | ||
| Degree of Corneal Astigmatism | Measurement Range | 0D~±10D | - | |
| Unit | 0.12D, 0.25D | - | ||
| Axis Angle | Measurement Range | 0°~180° | - | |
| Unit | 1° | - | ||
| PD MEASUREMENT | Measurement Range | 30mm - 85mm | 30mm - 85mm | |
| Unit | 1mm | 1mm | ||
| PUPIL DIAMETER MEASUREMENT | Measurement Range | ϕ2.0,mm~ϕ8.5,mm | ϕ2.0,mm~ϕ8.5,mm | |
| Unit | 0.1mm | 0.1mm | ||
| MECHANICAL SPECIFICATIONS | Size | (W) 288mm (D) 500mm (H) 480mm | - | |
| Movement range of the measurement unit | Forward/backward ±22mm Horizontal direction ±43mm Vertical direction ±17mm | - | ||
| Movement range of the chin rest | Vertical ±30mm | - | ||
| Movement range of the LCD | +40° tilt-able screen | - | ||
| Weight | Approx. 14kg | - | ||
| ELECTRICAL SPECIFICATIONS | Built-in monitor body | 5.7 Inch Color LCD Monitor | - | |
| Printer | Thermal printer with automatic cutter | - | ||
| Power voltage/frequency | AC100V-240V, 50/60 Hz | - | ||
| Power consumption | 60VA | - | ||
| Power saving function | OFF, 3, 5, 10 min (Selectable) | - | ||
