Autorefractometer AR-9
- Fashionable design with intelligent control
- Utilizes ARM processor for fast system response and clear image
- Incorporates Japan’s mature optical path system for precise measurements
- Stable measuring system with CNC machining
- 5.7 inch tiltable color LCD screen
- Automatic detachment printer for convenience
Description
The LENSit Auto-Refractometer AR-9 is a popular choice for eye care professionals looking for a reliable and efficient way to measure refractive errors. The AR-9 features an ARM processor for fast response times and clear image resolution. Additionally, the automatic mist measurement process helps to ensure precise measurements.
One of the key features of the AR-9 is its user-friendly design. The 5.7-inch tiltable color LCD screen can be adjusted for comfortable viewing, even from a standing position. The machine also comes with a built-in auto-detachment printer for easy record-keeping.
Specifications
| SPECIFICATIONS | KR-9 | AR-9 | ||
|---|---|---|---|---|
| REFRACTIVE MEASUREMENT RANGE | Sphere (S) | Measurement Range | -25D~+25D (VD=12) | -25D~+25D (VD=12) |
| Unit | 0.12D, 0.25D | 0.12D, 0.25D | ||
| Cylinder (C) | Measurement Range | 0D~±10D (VD=0) | 0D~±10D (VD=0) | |
| Unit | 0.12D, 0.25D | 0.12D, 0.25D | ||
| Symbol | -, +, ± | -, +, ± | ||
| Axis (A) | Measurement Range | 0°~180° | 1°0°~180° | |
| Unit | 1° | 1° | ||
| Vertex Distance | 0, 10, 12, 13.5, 15mm | 0, 10, 12, 13.5, 15mm | ||
| Minimum Pupil Diameter Measurable | ϕ2.0,mm | ϕ2.0mm | ||
| CORNEAL CURVATURE RADIUS MEASUREMENT | Corneal Curvature Radius | Measurement Range | 5.0mm - 10.mm | - |
| Unit | 0.01mm | - | ||
| Corneal Refractivity | Measurement Range | 33.00D~67.00D (where corneal refractive index n=1.3375) | - | |
| Unit | 0.12D, 0.25D | - | ||
| Degree of Corneal Astigmatism | Measurement Range | 0D~±10D | - | |
| Unit | 0.12D, 0.25D | - | ||
| Axis Angle | Measurement Range | 0°~180° | - | |
| Unit | 1° | - | ||
| PD MEASUREMENT | Measurement Range | 30mm - 85mm | 30mm - 85mm | |
| Unit | 1mm | 1mm | ||
| PUPIL DIAMETER MEASUREMENT | Measurement Range | ϕ2.0,mm~ϕ8.5,mm | ϕ2.0,mm~ϕ8.5,mm | |
| Unit | 0.1mm | 0.1mm | ||
| MECHANICAL SPECIFICATIONS | Size | (W) 288mm (D) 500mm (H) 480mm | - | |
| Movement range of the measurement unit | Forward/backward ±22mm Horizontal direction ±43mm Vertical direction ±17mm | - | ||
| Movement range of the chin rest | Vertical ±30mm | - | ||
| Movement range of the LCD | +40° tilt-able screen | - | ||
| Weight | Approx. 14kg | - | ||
| ELECTRICAL SPECIFICATIONS | Built-in monitor body | 5.7 Inch Color LCD Monitor | - | |
| Printer | Thermal printer with automatic cutter | - | ||
| Power voltage/frequency | AC100V-240V, 50/60 Hz | - | ||
| Power consumption | 60VA | - | ||
| Power saving function | OFF, 3, 5, 10 min (Selectable) | - | ||
